6 Stage SS Powder Coating System
Design: 30” W x 4’-0” H Opening, 10 FPM
scroll down for pics
Design Specifications:
• Part Opening: 30” W x 4’-0” H
• Maximum Product: 24’ W x 44’ H x 6’L (can be modified)
• Design Line Speed: 12 FPM (Variable <14)
• Condition: Very nice, Removed in 09/19
6- Stage Stainless Steel Washer
• Dwell Times @ 12 FPM:
• S1 – Clean (60 sec @ 140°F.); S2 – Clean (60 sec @ 140°F); S3 – Rinse (30 sec @ amb.); S4 – Rinse (30 sec @ amb.); S5 – Iron Phosphate (60 sec @ 130°F); S6 – Rinse (30 sec @ amb.) 12’ Drainbacks
• Stages 1, 2 & 5 – Heated with Hot Water Boiler (May be modified to Gas Imm. Tube)
• Haynes Pumps
• Dimensions: 12’-2” High x 10’-3” W x 48’ L
Dry-Off and Cure Oven –
• Dry-Off Oven.: 7’-9” W x 24’-10” L x 9’-2” H
• Dry-Off Oven Zones: 1
• Design / Max Temperature:, 500 Degree Peak Temp
• Time Cycle (Dry-Off): 6 minutes @ 10 FPM
• Time Cycle (Cure): 20 minutes @ 10 FPM
• Heating Gas fired Burner
• Oven Exhaust Fans, 2 per oven
• Adjustable Frames to move heaters closer to or further from part.
Cure Oven – Convection
• Dimensions: 17’ wide x 40’ long x 12’-0” high + BB
• Design / Max Temperature: <500° F
• Time Cycle: 5 minutes @ 10 FPM
• Heating Medium: Recirculating, direct- gas fired
• Floor-Mount Burner Box
• All Structure, Flashing, and Duct, Maxon Burners & Honeywell Controls, Oven Exhaust Fan and Entrance Air Hood Fan Provided
Conveyor System
• 600’ Long, enclosed track Conveyor System
• (1) Cat Drive & Take-Up, Oiler, (1) Lot Horizontal Turns
• Floor-Mount Structure
• Can be reconfigured as needed.
Installation services are available and may be quoted per customer request.
